Manual Trigger Mode 2D Wireless Barcode Reader with Scanning and ≥4mil Optical Resolution

Product Paramenters
U8 Specifications
Input voltage
DC 5 volts ± 0.25 volts
power
1.60 watts (working); 0.40 watts (standby).
current
320 mA (operating); 80 mA (standby) 5 +/-10% VDC @ 350 mA
sensor
Global Exposure CMOS
resolution
640 × 480 pixels
Transfer mode
USB charging cable as wired transmission data
Prompt mode
Buzzer, LED indicator
System interface
RS-232 serial port; USB keyboard; USB virtual serial port
Trigger mode
Manual, Auto-Sensing Mode, Continuous Scanning Mode
Exterior dimensions
Length× width× height: 165mm×67mm×97mm
weight
180g (without cable).
Cable standards
Straight line, 1 6 meters
The interface type
One-piece line
Shell material
PC+ABS
Temperature
0°C to 50°C (operating); -40°C to 60°C (storage).
Humidity
5% to 95% (non-condensing).
How to set up
Manual (scan and set up barcodes in turn)
Symbolic contrast
≥15%
Read accuracy
QR code 3MIL(Code39,CODE128,EAN13), QR code 5MIL(QR, DM, PDF417).
